PRODUCT INTRODUCTION


  Vacuum system, efficient operation

Its mechanical-vacuum system allows both heavy and bulky material to be collected. This system , along with four large wheels, allows quick sweeping without causing disturbance.

  Scientifically and environmentally friendly, suppression of dust and powder

With the mechanical-vacuum system , the roller brush removes the heavy dirt from the ground and throws it into the hopper, whilst the powerful turbine vacuums the dust and holds it in the filter without using water.

  Wide operating occasions, fast and efficient

On dry surfaces it sweeps without wasting water as its filter holds the fine dust. On wet surface it continues to sweep without the filter.

  User-friendly design, stable and comfortable

The four 13 inch wheels pay attention to humanization design and make the machine very stable and comfortable for transfer and when climbing steps.

  Intelligent product, continuous operation

It can clean both right and left and moves easily to reach dirt also in the most difficult coners.




TECHNICAL CHARACTERISTICS
TECHNICAL SPECIFICATIONS
  UNIT M3
HOURLY PERFORMANCE m²/h 16000
MAXIMUM CLEANING WIDTH(WITH 2 SIDE BRUSHES) mm 1600
MAXIMUM CLEANING WIDTH(WITH 3 SIDE BRUSHES) mm 1900
HOPPER CAPACITY lt 310
HOPPER EMPTYING mm 1350
WATER TANK lt 80
ENGINE   Kubota Diesel
NO.OF CYLINDERS   3
COOLING   Acqua Water
INSTALLED POWER HP/KW 27/20
MAXIMUM SPEED Km/h 18
TRACTION   Hydrostatic
DIMENSIONS mm 2619 x 1032 x 1940
WEIGHT Kg 1270
FUNCTION SHEET
1.Front brush 2.Side brush
3.Roller brush 4.Hopper
5.Dust filters 6.Vacuum fan
7.Water tank 8.Motore engine
